This is a direct replacement pump for obsolete Leybold SC-5 / PN 133100
The Anest Iwata ISP-90 Dry Scroll Pumps provide a clean dry vacuum enviroment. These Vacuum Pumps also eliminate the nuisance of cumbersome lubricant maintenance or sealing water administration.
The ISP-90 Dry Pump does not require water cooling. It is free from installation restrictions because of its air-cooled system.
The Anest Iwata ISP-90 Scroll Vacuum Pump is equipped with Air Flush Port, which pumps out the remaining moisture left over from pumping humid gases and maintains the ultimate pressure.
Anest Iwata ISP-90 series vacuum pumps maintain low power consumption from atmosphere to maximum pressure.
This pumping system is suitable for clean processes only. It cannot be used with explosive, flammable, toxic or corrosive substances or substances which contain chemicals, solvents or particles.
The ISP-90 Oil Free Vacuum Pump should be operated at temperature within the range of 5ºC to 40ºC.
Sputtering Equipment, Vacuum Depostition Equipment, Ion Plating Equipment
Accelerator, Synchrotron Radiation
Surface Modification, Electron Beam Process
Gas Recovery Devices
Vacuum Equipment
Leak Detectors
Device Handling System
Vacuum Furnace, Heat Treatment Furnace
Laboratory Use
Vacuum Packaging Machine
Click Here to view Anest Iwata ISP-90 Dry Scroll Vacuum Pump Instruction Manual.
A&J Vacuum Services, Inc is Anest Iwata authorized repair / rebuild and service center for all Scroll Dry Vacuum Pumps along with all other. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
This is a direct replacement pump for obsolete Leybold SC-5 / PN 133100
Click Here to view Anest Iwata ISP-90 Dry Scroll Vacuum Pump Instruction Manual.
A&J Vacuum Services, Inc is Anest Iwata authorized repair / rebuild and service center for all Scroll Dry Vacuum Pumps along with all other. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
A & J Vacuum Services provides repair service for all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair, Mass Spectrometer repair, Rotary Vane Pump repair, Vacuum Booster repair, and Leak detector repair. Our highly trained technicians have years of experience and guarantee the highest quality service.
We operate at our own full service repair facility in Clifton, NJ. We have invested in state-of-the-art equipment including; complete line of decontamination, cleaning, drying, balancing, vibration analysis and software to minimize failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.
We support all major manufacturers including Pfeiffer Vacuum, Alcatel / Adixen, Edwards Vacuum, Varian, Oerlikon / Leybod Vacuum, Vacuubrand, and Agilent Technologies.
Repair Steps
Every pump and instrument is extensively tested for 48 hours. During our final tests, we monitor total pressure, temperature, vibration and noise level utilizing newest testing technologies and techniques specified by OEM. Upon request, we can provide our customers with a pump down graph. Call us for your free repair estimate at 1-973-249-0854.
