Overview:
The Edwards Vacuum EH/QMB 250 / EH/QMB 500 Major Reapir/Rebuild Kit includes everything needed for major overhauls on Edwards Rotary Vane Vacuum Pumps.
We also do minor and major repairs for all Edwards Rotary Vane Vacuum Pumps.
EH 250/EH 500 Major Reapir/Rebuild Kit contains the following parts:
DESCRIPTION | PART NO. | QTY |
Dowty Seal | E02104004 | 2 |
Dowty Seal | E02104008 | 1 |
Shaft Seal | E02109052 | 4 |
Shaft Seal | E02109075 | 4 |
Shaft Seal | E02109120 | 2 |
Viton O-Ring | E02120077V | 1 |
Viton O-Ring | E02122009V | 2 |
Viton O-Ring | E02122091 | 1 |
Viton O-Ring | E02125028V | 6 |
Bearing - 6304ZZ | E20403010 | 2 |
Bearing - 6304DDUC3 | E20403025 | 2 |
Inner Race | E20405024 | 4 |
Bearing | E21631027 | 2 |
Felt Dust Ring | E22302005 | 4 |
Felt Filters - with Hole | E22302015 | 11 |
Felt Filters - Solid | E22302016 | 2 |
Vion O-Ring | E23714034 | 7 |
Vion O-Ring | E23714036 | 1 |
Vion O-Ring | E23714037 | 1 |
Vion O-Ring | E23717001 | 1 |
Viton Seal | E27159500 | 1 |
Viton Gasket | E27159547 | 1 |
Shim - 0.20 mm | E27165008 | 3 |
Shim - 0.25 mm | E27165009 | 3 |
Shim - 0.125 mm | E27165032 | 3 |
Inner Race | E27801025 | 2 |
Sight Glass | E29201004 | 3 |
THERE ARE NO RETURNS ON THIS PRODUCT.
Edwards EH/QMB250 / EH/QMB 500 Major Repair/Rebuild Kit, 30151800
A & J Vacuum Services provides repair service for all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair, Mass Spectrometer repair, Rotary Vane Pump repair, Vacuum Booster repair, and Leak detector repair. Our highly trained technicians have years of experience and guarantee the highest quality service.
We operate at our own full service repair facility in Clifton, NJ. We have invested in state-of-the-art equipment including; complete line of decontamination, cleaning, drying, balancing, vibration analysis and software to minimize failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.
We support all major manufacturers including Pfeiffer Vacuum, Alcatel / Adixen, Edwards Vacuum, Varian, Oerlikon / Leybod Vacuum, Vacuubrand, and Agilent Technologies.
Repair Steps
Every pump and instrument is extensively tested for 48 hours. During our final tests, we monitor total pressure, temperature, vibration and noise level utilizing newest testing technologies and techniques specified by OEM. Upon request, we can provide our customers with a pump down graph. Call us for your free repair estimate at 1-973-249-0854.
