The Pfeiffer Adixen 2021 C2 Pascal Dual-Stage Rotary Vane Pump arrives coupled with standardized Model 25 ISO-KF Inlet and Outlet Flanges. This Pfeiffer Rotary Vane Pump has a peak pumping velocity of 22 m^(3)/h and a final pressure of 5 x 10^(-4) hPa. The Pfeiffer Adixen 2021 C2 Pascal pump is corrosive (wet version) and requires 1.86 kg of PFPE Operating Vacuum Fluid for maximum operating efficiency.
Pfeiffer Vacuum manufactures some of the most widely-utilized varieties of advanced rotary vane used in a variety of industrial applications in the twenty-first century, including laboratory processes, chemical and process engineering, among others. These products are ideally utilized for the low-to-medium intensity vacuum range. Pfeiffer vacuum pumps are especially known for their durability and wide range of application.
A rotary vane pump functions as a displacement pump, creating a low-pulsation suction volume flow. Rotary vane pumps include an eccentrically-supported rotor with two rotating vanes, encased and revolving within a housing. The Pfeiffer Rotary Vane Pumps offered to our clients are oil-lubricated (wet-version pumps); these operating fluids help to enhance the insulation of pump components and ensure maximum durability and efficiency of the product.
We offer both single-stage and dual-stage Pfeiffer Rotary Vane Vacuum Pumps on our website. Single-stage pumps are the preferred choice for low-intensity vacuum applications, while dual-stage pumps are the recommended choices for the medium and upper intensity range of vacuum applications.
A&J Vacuum services and repairs Pfeiffer 2021 C2 Pascal Rotary Vane Pumps well as all other Pfeiffer Rotary Vane and Turbo Pumps available on our website. Please contact us for additional information concerning our service program or click http://www.ajvs.com/service.php to access our Services page. We likewise offer emergency service and repair upon request. For more information, please contact A&J Vacuum Services at (973) 249-0854. Thank you for choosing AJVS as your supplier.
Inlet Flange: | DN 25 |
Outlet Flange: | DN 25 |
Nominal Pumping Speed (50 Hz): | 14.6 cfm |
Ultimate Pressure (closed): | 2 x 10-3 mbar |
Ultimate Pressure (open): | 10-2 mbar |
Water Vapor Pressure (50 Hz): | 7 mbar |
Noise Level (50 Hz): | 50 dBA |
Oil Capacity: | 0.98 l |
Weight: | 67 lbs |
A&J Vacuum services and repairs Pfeiffer Alcatel 2021 C1 Pascal Dual-Stage Rotary Vane Pumps, along with all other Pfeiffer Rotary Vane and Turbo Pumps offered on our website. Please contact us for additional information regarding our service program or visit http://www.ajvs.com/service.php to access our Services page. We likewise offer emergency service and repair upon request. If you have any questions or would like to obtain additional information, please call A&J Vacuum Services at (973) 249-0854. Thank you for choosing AJVS as your supplier.
A & J Vacuum Services provides repair service for all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair, Mass Spectrometer repair, Rotary Vane Pump repair, Vacuum Booster repair, and Leak detector repair. Our highly trained technicians have years of experience and guarantee the highest quality service.
We operate at our own full service repair facility in Clifton, NJ. We have invested in state-of-the-art equipment including; complete line of decontamination, cleaning, drying, balancing, vibration analysis and software to minimize failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.
We support all major manufacturers including Pfeiffer Vacuum, Alcatel / Adixen, Edwards Vacuum, Varian, Oerlikon / Leybod Vacuum, Vacuubrand, and Agilent Technologies.
Repair Steps
Every pump and instrument is extensively tested for 48 hours. During our final tests, we monitor total pressure, temperature, vibration and noise level utilizing newest testing technologies and techniques specified by OEM. Upon request, we can provide our customers with a pump down graph. Call us for your free repair estimate at 1-973-249-0854.
