Edwards RV 12 (RV12) Major Overhaul / Rebuild Maintenance Kit, 65201131 RV12
Item#: PN01515 Mfr Part#: 65201131RV12 Manufacturer: Edwards Vacuum
Condition: New In Stock
New Edwards RV 12 (RV12) Major Overhaul / Rebuild Maintenance Kit, A65201131RV12

Features:
  • P/N A65201131
  • Major Overhaul / Rebuild Maintenance Kit

PRICE: $399.00
YOU PAY: $462.00
Item#: PN01515 Mfr Part#: 65201131RV12
Edwards RV 12 (RV12) Major Overhaul / Rebuild Maintenance Kit, 65201131 RV12
Item#: PN01515 Mfr Part#: 65201131RV12 Manufacturer: Edwards Vacuum

Edwards RV 12 (RV12) Major Overhaul / Rebuild Maintenance Kit, A65201131 RV12, A652-01-131



The Edwards RV12 Major Overhaul Kit includes everything needed for major overhauls on the Edwards RV12 Rotary Vane Vacuum Pump.


A&J Vacuum Repair / Rebuild and Rervice all Edwards RV3, RV5, RV8, RV12, E2M2, E2M5, E2M8, E2M12 Series  Vacuum Pumps  along with all other Edwards  Turbo Pumps, Edwards Dry Pumps, Edwards Scroll Pumps and all other Edwards Vacuum Rotary Vane pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854



This item is non-returnable/non-refundable

Edwards RV 12 (RV12) Major Overhaul / Rebuild Maintenance Kit, A65201131 RV12, A652-01-131


Edwards RV12 Major Overhaul Kit contains the following parts:

DESCRIPTION PART NO. QTY
Air Bleed Assembly 65201005 1
Viton Shaft Seal (Inner) E02109066 1
Viton Shaft Seal (Outer) E02109124 1
Shaft Seal Spacer E02109125 1
O-Ring E02120036 1
O-Ring E02120037 1
O-Ring E02120077 1
O-Ring E02122031 1
O-Ring E02122055 1
O-Ring E02125026 3
Oil Pump Vane E20402500G 1
1st Stage Vane E20402528G 2
2nd Stage Vane E20402530G 2
Spring (Dump&Check) E20525047 2
Spring (G/B Control) E20525048 1
Spring (C/B Control) E20525049 1
Coupling Element E21071077 1
O-Ring E23712039 1
O-Ring E23724070 1
O-Ring E23724071 1
O-Ring E23724072 1
O-Ring E23724073 3
Exhaust Diaphragm E25908123 1
Coupling E25908127 1
Oil Pressure Valve E25908129 1
Dump Valve E25908226 1
G/B Check Valve E26501036 1
U-Seal E26501040 1
Mounting Foot E26501041 4
Shouldered Washer E27154018 1
Gasket (Oil Box) E27160005 1
Gasket (Cartridge) E27160006 1
Gasket (Top Plate) E27160007 1
Gasket (Seal) E27160008 1
Motor Gasket E65201019 1
Reed Valve E65201029 1
Valve Pad E70000557 1

A&J Vacuum Repair / Rebuild and Rervice all Edwards RV3, RV5, RV8, RV12, E2M2, E2M5, E2M8, E2M12 Series  Vacuum Pumps  along with all other Edwards  Turbo Pumps, Edwards Dry Pumps, Edwards Scroll Pumps and all other Edwards Vacuum Rotary Vane pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854




| Service and Repair
We can repair your:
  • Turbo Pumps
  • Rotary Vane Pumps
  • Dry Vacuum Pumps
  • Leak Detectors
  • Scroll Dry Pumps
  • Vacuum Boosters
  • Diaphragm Dry Pumps
You trusted worldwide leader of High Vacuum equipment!
Call us for your free repair estimate!
973-249-0854

A & J Vacuum Services provides repair service for all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair, Mass Spectrometer repair, Rotary Vane Pump repair, Vacuum Booster repair, and Leak detector repair. Our highly trained technicians have years of experience and guarantee the highest quality service.

We operate at our own full service repair facility in Clifton, NJ. We have invested in state-of-the-art equipment including; complete line of decontamination, cleaning, drying, balancing, vibration analysis and software to minimize failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.

We support all major manufacturers including Pfeiffer Vacuum, Alcatel / Adixen, Edwards Vacuum, Varian, Oerlikon / Leybod Vacuum, Vacuubrand, and Agilent Technologies.

Repair Steps

  1. Full incoming inspection and run up time check, vibration check, drive inspection.
  2. Full disassembly, decontamination and cleaning.
  3. Pump is balanced utilizing state-of-the-art equipment from the world leader in equipment balancing and analysis to reduce noise and vibrations and extend bearings life.
  4. Assembly and replacement of all necessary parts such as shafts, bushings, bearings, sleeves, O-rings, gaskets, seals, wicks, etc. Only parts that meet or surpass OEM specifications are used to ensure dependable highest quality service and long pump life.
  5. Final test and leak check. The pump in fully assembled condition is checked for vacuum seal. Leak test to 1 x 10-9 Mbar l/s. Vibrations are analyzed and test data is digitally recorded.

Every pump and instrument is extensively tested for 48 hours. During our final tests, we monitor total pressure, temperature, vibration and noise level utilizing newest testing technologies and techniques specified by OEM. Upon request, we can provide our customers with a pump down graph. Call us for your free repair estimate at 1-973-249-0854.

Overview

Edwards RV 12 (RV12) Major Overhaul / Rebuild Maintenance Kit, 65201131 RV12
Item#: PN01515 Mfr Part#: 65201131RV12 Manufacturer: Edwards Vacuum

Edwards RV 12 (RV12) Major Overhaul / Rebuild Maintenance Kit, A65201131 RV12, A652-01-131



The Edwards RV12 Major Overhaul Kit includes everything needed for major overhauls on the Edwards RV12 Rotary Vane Vacuum Pump.


A&J Vacuum Repair / Rebuild and Rervice all Edwards RV3, RV5, RV8, RV12, E2M2, E2M5, E2M8, E2M12 Series  Vacuum Pumps  along with all other Edwards  Turbo Pumps, Edwards Dry Pumps, Edwards Scroll Pumps and all other Edwards Vacuum Rotary Vane pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854



Edwards RV 12 (RV12) Major Overhaul / Rebuild Maintenance Kit, A65201131 RV12, A652-01-131


Edwards RV12 Major Overhaul Kit contains the following parts:

DESCRIPTION PART NO. QTY
Air Bleed Assembly 65201005 1
Viton Shaft Seal (Inner) E02109066 1
Viton Shaft Seal (Outer) E02109124 1
Shaft Seal Spacer E02109125 1
O-Ring E02120036 1
O-Ring E02120037 1
O-Ring E02120077 1
O-Ring E02122031 1
O-Ring E02122055 1
O-Ring E02125026 3
Oil Pump Vane E20402500G 1
1st Stage Vane E20402528G 2
2nd Stage Vane E20402530G 2
Spring (Dump&Check) E20525047 2
Spring (G/B Control) E20525048 1
Spring (C/B Control) E20525049 1
Coupling Element E21071077 1
O-Ring E23712039 1
O-Ring E23724070 1
O-Ring E23724071 1
O-Ring E23724072 1
O-Ring E23724073 3
Exhaust Diaphragm E25908123 1
Coupling E25908127 1
Oil Pressure Valve E25908129 1
Dump Valve E25908226 1
G/B Check Valve E26501036 1
U-Seal E26501040 1
Mounting Foot E26501041 4
Shouldered Washer E27154018 1
Gasket (Oil Box) E27160005 1
Gasket (Cartridge) E27160006 1
Gasket (Top Plate) E27160007 1
Gasket (Seal) E27160008 1
Motor Gasket E65201019 1
Reed Valve E65201029 1
Valve Pad E70000557 1

A&J Vacuum Repair / Rebuild and Rervice all Edwards RV3, RV5, RV8, RV12, E2M2, E2M5, E2M8, E2M12 Series  Vacuum Pumps  along with all other Edwards  Turbo Pumps, Edwards Dry Pumps, Edwards Scroll Pumps and all other Edwards Vacuum Rotary Vane pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854




We can repair your:
  • Turbo Pumps
  • Rotary Vane Pumps
  • Dry Vacuum Pumps
  • Leak Detectors
  • Scroll Dry Pumps
  • Vacuum Boosters
  • Diaphragm Dry Pumps
You trusted worldwide leader of High Vacuum equipment!
Call us for your free repair estimate!
973-249-0854

A & J Vacuum Services provides repair service for all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair, Mass Spectrometer repair, Rotary Vane Pump repair, Vacuum Booster repair, and Leak detector repair. Our highly trained technicians have years of experience and guarantee the highest quality service.

We operate at our own full service repair facility in Clifton, NJ. We have invested in state-of-the-art equipment including; complete line of decontamination, cleaning, drying, balancing, vibration analysis and software to minimize failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.

We support all major manufacturers including Pfeiffer Vacuum, Alcatel / Adixen, Edwards Vacuum, Varian, Oerlikon / Leybod Vacuum, Vacuubrand, and Agilent Technologies.

Repair Steps

  1. Full incoming inspection and run up time check, vibration check, drive inspection.
  2. Full disassembly, decontamination and cleaning.
  3. Pump is balanced utilizing state-of-the-art equipment from the world leader in equipment balancing and analysis to reduce noise and vibrations and extend bearings life.
  4. Assembly and replacement of all necessary parts such as shafts, bushings, bearings, sleeves, O-rings, gaskets, seals, wicks, etc. Only parts that meet or surpass OEM specifications are used to ensure dependable highest quality service and long pump life.
  5. Final test and leak check. The pump in fully assembled condition is checked for vacuum seal. Leak test to 1 x 10-9 Mbar l/s. Vibrations are analyzed and test data is digitally recorded.

Every pump and instrument is extensively tested for 48 hours. During our final tests, we monitor total pressure, temperature, vibration and noise level utilizing newest testing technologies and techniques specified by OEM. Upon request, we can provide our customers with a pump down graph. Call us for your free repair estimate at 1-973-249-0854.
