The CR series is an air-cooled roots type dry vacuum pump. Stable operation and extended lifetime are possible because there is no oil inside of teh pump head and no contact between rotor and cylinder.
A&J Vacuum Services offers full repair/service of Ulvac Vacuum Pumps, along with all other brands offered on our website. AJVS also services Ulvac turbo pumps and rotary vane pumps. Please contact us for information about our service and repair program or click http://www.ajvs.com/service.php to access our services page. We also offer emergency service upon request. For more information, please email A&J Vacuum Services at info@ajvs.com or call (973) 249-0854. Thank you for choosing AJVS as your supplier.
Pumping Speed: | 9.8 cfm |
Ultimate Pressure: | < 2 x 10-2 Torr |
Motor rating: | 0.72 kW |
Inlet Flange: | DN 25 KF |
Outlet Flange: | DN 25 KF |
Length: | 20.47 inches |
Width: | 7.087 inches |
Height: | 13.78 inches |
Weight: | 35 kg / 77 lbs |
A&J Vacuum Services offers full repair/service of Ulvac Vacuum Pumps, along with all other brands offered on our website. AJVS also services Ulvac turbo pumps and rotary vane pumps. Please contact us for information about our service and repair program or click http://www.ajvs.com/service.php to access our services page. We also offer emergency service upon request. For more information, please email A&J Vacuum Services at info@ajvs.com or call (973) 249-0854. Thank you for choosing AJVS as your supplier.
A & J Vacuum Services provides repair service for all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair, Mass Spectrometer repair, Rotary Vane Pump repair, Vacuum Booster repair, and Leak detector repair. Our highly trained technicians have years of experience and guarantee the highest quality service.
We operate at our own full service repair facility in Clifton, NJ. We have invested in state-of-the-art equipment including; complete line of decontamination, cleaning, drying, balancing, vibration analysis and software to minimize failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.
We support all major manufacturers including Pfeiffer Vacuum, Alcatel / Adixen, Edwards Vacuum, Varian, Oerlikon / Leybod Vacuum, Vacuubrand, and Agilent Technologies.
Repair Steps
Every pump and instrument is extensively tested for 48 hours. During our final tests, we monitor total pressure, temperature, vibration and noise level utilizing newest testing technologies and techniques specified by OEM. Upon request, we can provide our customers with a pump down graph. Call us for your free repair estimate at 1-973-249-0854.
