Alcatel 122L Industrial Dry Vacuum Pump, also known as Adixen 122 L Pump
Alcatel 122L Overview:
• Wide interstage channels are able to accommodate large quantities of powder and particles.
• High operating temperature with a precise closed-loop temperature management system, and a linear increase of gas temperature from inlet to outlet makes ADP 122 one of the best on market
• Vertical pumping on each stage which prevents particulate accumulation in the swept volume.
Semiconductor fab rules compliant:
• Compact: the series 2 model is only 390 mm wide.
• Clean: Alcatel technology is a frictionless and oil-free pump mechanism. There is no risk of particulate contamination.
• Quiet: All models include an integrated silencer, eliminating the need for an additional external silencer.
• Semi S2 compliant.
ADP 122 L has a Low cost of ownership
• Low power consumption at working pressures and at Ultimate Pressure.
• With moderate heat generation, series 2 water consumption is extremely low.
• Nitrogen Purge level is easily set by the customer. Pumps for clean applications do not require any purge.
Typical applications:
• ADP 122 LM, ADS 602 LM:
Load Lock, Transfer Chambers, PVD, Sputtering
• ADP 122 P, ADS 602 P, ADS 1202 P, ADS 1802 P:
Ashing, Stripping, Dielectric - Poly Etch, Implant Source, Medium CVD
• ADS 602 H, ADS 1202 H, ADS 1802 H:
PECVD, LPCVD
Alcatel 122 L Dimensions:
Click Here for Alcatel ADP 122L Manual
A&J Vacuum Services offers full repair/service of Pfeiffer Vacuum Pumps, along with all other brands offered on our website. AJVS also services Pfeiffer turbo pumps and rotary vane pumps. Please contact us for information about our service and repair program or click http://www.ajvs.com/service.php to access our services page. We also offer emergency service upon request. For more information, please email A&J Vacuum Services at info@ajvs.com or call (973) 249-0854. Thank you for choosing AJVS as your supplier.
Alcatel 122L Industrial Dry Vacuum Pump, also known as Adixen 122 L Pump
Alcatel 122L Dimensions:
Click Here for Alcatel ADP 122L Manual
A&J Vacuum Services offers full repair/service of Pfeiffer Vacuum Pumps, along with all other brands offered on our website. AJVS also services Pfeiffer turbo pumps and rotary vane pumps. Please contact us for information about our service and repair program or click http://www.ajvs.com/service.php to access our services page. We also offer emergency service upon request. For more information, please email A&J Vacuum Services at info@ajvs.com or call (973) 249-0854. Thank you for choosing AJVS as your supplier.
Alcatel ADP 122, Adixen ADP 122, ADP122 Manual, Adixen ADP122 Manual
|
Service and Repair - Turbo Pumps
- Rotary Vane Pumps
- Dry Vacuum Pumps
- Leak Detectors
- Scroll Dry Pumps
- Vacuum Boosters
- Diaphragm Dry Pumps
A & J Vacuum Services provides repair service for all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair, Mass Spectrometer repair, Rotary Vane Pump repair, Vacuum Booster repair, and Leak detector repair. Our highly trained technicians have years of experience and guarantee the highest quality service.
We operate at our own full service repair facility in Clifton, NJ. We have invested in state-of-the-art equipment including; complete line of decontamination, cleaning, drying, balancing, vibration analysis and software to minimize failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.
We support all major manufacturers including Pfeiffer Vacuum, Alcatel / Adixen, Edwards Vacuum, Varian, Oerlikon / Leybod Vacuum, Vacuubrand, and Agilent Technologies.
Repair Steps
- Full incoming inspection and run up time check, vibration check, drive inspection.
- Full disassembly, decontamination and cleaning.
- Pump is balanced utilizing state-of-the-art equipment from the world leader in equipment balancing and analysis to reduce noise and vibrations and extend bearings life.
- Assembly and replacement of all necessary parts such as shafts, bushings, bearings, sleeves, O-rings, gaskets, seals, wicks, etc. Only parts that meet or surpass OEM specifications are used to ensure dependable highest quality service and long pump life.
- Final test and leak check. The pump in fully assembled condition is checked for vacuum seal. Leak test to 1 x 10-9 Mbar l/s. Vibrations are analyzed and test data is digitally recorded.
Every pump and instrument is extensively tested for 48 hours. During our final tests, we monitor total pressure, temperature, vibration and noise level utilizing newest testing technologies and techniques specified by OEM. Upon request, we can provide our customers with a pump down graph. Call us for your free repair estimate at 1-973-249-0854.
