Alcatel Adixen, Minor Repair Kit for Adixen 2063 C1 and 2063 C Vacuum Pumps, PN 54488
Overview
The Alcatel Adixen 2063 C1 and 2063 C Minor Repair / Rebuild Kit includes everything needed for minor overhauls on the Alcatel Adixen 2063 C1 and 2063 C Rotary Vane Vacuum Pumps. The parts included in the Alcatel Adixen Minor Repair Kit are high quality components used in rotary vane vacuum pump maintenance, service, and repairs. Minor and major repair kits for all Alcatel Adixen 2063 C1 and 2063 C Pump Models are also available. We offer high quality spare parts, such as rotors, stators, plates, vanes, and shaft seals for all Alcatel Adixen 2063 C1 and 2063 C Rotary Vane Vacuum Pumps.
Alcatel Adixen, 2063 C1 and 2063 C Minor Repair Kit contains the following parts:
| DESCRIPTION | PART NO. | QTY |
|
Sight Glass Gasket |
103306 |
1 |
|
Sight Glass |
103307 |
1 |
|
O-Ring, 63.09 x 3.53 mm |
320067 |
1 |
|
Valve |
53443 |
3 |
|
Exhaust Valve |
54134 |
1 |
|
Spring |
54145 |
1 |
|
Spring |
54149 |
1 |
|
Oil Pump Membrane |
54196 |
1 |
|
Sight Glass Assy |
54197 |
1 |
|
Clapper |
54224 |
1 |
|
Elastic Coupling |
54356 |
1 |
|
Case Gasket |
54427 |
1 |
|
Felt Pad |
65538 |
1 |
|
C-Clip |
71188 |
2 |
|
C-Clip |
71191 |
1 |
|
Nut |
71338 |
1 |
|
Waved Washer, M10 |
73446 |
25 |
|
Waved Washer, M6 |
73460 |
21 |
|
Waved Washer, M8 |
73461 |
2 |
|
Screw |
75024 |
1 |
|
Cotter Pin |
76261 |
1 |
|
C-Clip |
76261C |
1 |
|
Shaft Seal |
79101 |
4 |
|
O-Ring, 8 x 2 mm |
79134 |
2 |
|
O-Ring, 95 x 3 mm |
79136 |
1 |
|
O-Ring, 148 x 2 mm |
79137 |
4 |
|
O-Ring, 10.77 x 2.62 mm |
82007 |
1 |
|
O-Ring, 40.64 x 5.33 mm |
82013 |
1 |
|
O-Ring, 9.19 x 2.62 mm |
82015 |
1 |
|
O-Ring, 17.12 x 2.62 mm |
82022 |
1 |
|
O-Ring, 29.3 x 3.6 mm |
82025 |
2 |
|
O-Ring, 91.44 x 5.33 |
82027 |
1 |
|
O-Ring, 37 x 2.5 mm |
82056 |
1 |
|
O-Ring, 44 x 3 mm |
82067 |
3 |
|
Plastic Drain Plug |
82604 |
1 |
| Fill Plug | 82925 | 1 |
| Valve Spring | 87954 | 3 |
| Carton | U30007191 | 1 |
| Vane | 65514G | 1 |
A&J Vacuum Services, Inc. Repairs / Rebuilds and Services Alcatel Adixen Vacuum Pumps including Alcatel Adixen Rotary Vane Pumps, Pascal Series, SD Series, CP, CP+ and C. Along with all other Vacuum Rotary Vane Pumps, Dry Scroll Pumps, Leak Detectors. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
