Alcatel Adixen, Major Repair Kit for Adixen 2063 C1 and 2063 C Vacuum Pumps, PN 54489, 54489KIT
Overview:
The Alcatel / Adixen 2063 C/C1 Rotary Vane Vacuum Pump Major Repair / Rebuild Kit includes everything needed for major overhauls on the Alcatel / Adixen 2063 C/C1 Rotary Vane Vacuum Pump.
We also do minor and major repairs for all Alcatel / Adixen Rotary Vane Vacuum Pumps.
Alcatel / Adixen 2063C/C1 Major Repair / Rebuild Kit contains the following parts:
DESCRIPTION | PART NO. | QTY |
Viton Valve |
A53443 |
3 |
Exhaust Valve |
A54134 |
1 |
Spring |
A54145 |
1 |
Spring |
A54149 |
1 |
Membrane |
A54196 |
1 |
Sight Glass Disk |
A54199 |
1 |
Clapper |
A54224 |
1 |
Coupling |
A54356 |
1 |
1st Stage Vane |
A54400G |
2 |
2nd Stage Vane |
A54401G |
2 |
Oil Case Gasket |
A54427 |
1 |
Oil Pump Vane |
A65042G |
1 |
Felt Pad |
A65059 |
1 |
C-Clip |
A71188 |
2 |
Nut |
A71217 |
17 |
Waved Washer M5 |
A73453 |
3 |
Waved Washer M6 |
A73454 |
21 |
Waved Washer M8 |
A73455 |
2 |
Waved Washer M10 |
A73456 |
25 |
Socket Head Screw |
A75024 |
1 |
C-Clip |
A76261C |
2 |
Viton Shaft Seal |
A79101 |
4 |
O-Ring |
A79134 |
2 |
O-Ring |
A79136 |
1 |
O-Ring |
A79137 |
4 |
O-Ring |
A79327 |
1 |
O-Ring |
A82007 |
4 |
O-Ring |
A82013 |
2 |
O-Ring |
A82015 |
1 |
O-Ring |
A82022 |
1 |
O-Ring |
A82025 |
2 |
O-Ring |
A82027 |
2 |
O-Ring |
A82056 |
1 |
O-Ring |
A82067 |
3 |
Drain Plug |
A82604 |
1 |
Fill Plug |
A82925 |
1 |
Waved Washer |
A84646 |
2 |
Vane Spring |
A87942 |
9 |
Valve Spring |
A87954 |
3 |
THERE ARE NO RETURNS ON THIS PRODUCT.
Overview
The Alcatel Adixen 2063 C2 and 2063 C Major Repair / Rebuild Kit includes everything needed for minor overhauls on the Alcatel Adixen 2063 C2 and 2063 C Rotary Vane Vacuum Pumps. The parts included in the Alcatel Adixen Major Repair Kit are high quality components used in rotary vane vacuum pump maintenance, service, and repairs. Minor and major repair kits for all Alcatel Adixen 2063 C2 and 2063 C Pump Models are also available. We offer high quality spare parts, such as rotors, stators, plates, vanes, and shaft seals for all Alcatel Adixen 2063 C2 and 2063 C Rotary Vane Vacuum Pumps.
Alcatel Adixen, 2063 C2 and 2063 C Major Repair Kit contains the following parts:
DESCRIPTION | PART NO. | QTY |
Viton Valve |
A53443 |
3 |
Exhaust Valve |
A54134 |
1 |
Spring |
A54145 |
1 |
Spring |
A54149 |
1 |
Membrane |
A54196 |
1 |
Sight Glass Disk |
A54199 |
1 |
Clapper |
A54224 |
1 |
Coupling |
A54356 |
1 |
1st Stage Vane |
A54400G |
2 |
2nd Stage Vane |
A54401G |
2 |
Oil Case Gasket |
A54427 |
1 |
Oil Pump Vane |
A65042G |
1 |
Felt Pad |
A65059 |
1 |
C-Clip |
A71188 |
2 |
Nut |
A71217 |
17 |
Waved Washer M5 |
A73453 |
3 |
Waved Washer M6 |
A73454 |
21 |
Waved Washer M8 |
A73455 |
2 |
Waved Washer M10 |
A73456 |
25 |
Socket Head Screw |
A75024 |
1 |
C-Clip |
A76261C |
2 |
Viton Shaft Seal |
A79101 |
4 |
O-Ring |
A79134 |
2 |
O-Ring |
A79136 |
1 |
O-Ring |
A79137 |
4 |
O-Ring |
A79327 |
1 |
O-Ring |
A82007 |
4 |
O-Ring |
A82013 |
2 |
O-Ring |
A82015 |
1 |
O-Ring |
A82022 |
1 |
O-Ring |
A82025 |
2 |
O-Ring |
A82027 |
2 |
O-Ring |
A82056 |
1 |
O-Ring |
A82067 |
3 |
Drain Plug |
A82604 |
1 |
Fill Plug |
A82925 |
1 |
Waved Washer |
A84646 |
2 |
Vane Spring |
A87942 |
9 |
Valve Spring |
A87954 |
3 |
A&J Vacuum Services, Inc. Repairs / Rebuilds and Services Alcatel Adixen Vacuum Pumps including Alcatel Adixen Rotary Vane Pumps, Pascal Series, SD Series, CP, CP+ and C. Along with all other Vacuum Rotary Vane Pumps, Dry Scroll Pumps, Leak Detectors. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
.
A & J Vacuum Services provides repair service for all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair, Mass Spectrometer repair, Rotary Vane Pump repair, Vacuum Booster repair, and Leak detector repair. Our highly trained technicians have years of experience and guarantee the highest quality service.
We operate at our own full service repair facility in Clifton, NJ. We have invested in state-of-the-art equipment including; complete line of decontamination, cleaning, drying, balancing, vibration analysis and software to minimize failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.
We support all major manufacturers including Pfeiffer Vacuum, Alcatel / Adixen, Edwards Vacuum, Varian, Oerlikon / Leybod Vacuum, Vacuubrand, and Agilent Technologies.
Repair Steps
Every pump and instrument is extensively tested for 48 hours. During our final tests, we monitor total pressure, temperature, vibration and noise level utilizing newest testing technologies and techniques specified by OEM. Upon request, we can provide our customers with a pump down graph. Call us for your free repair estimate at 1-973-249-0854.
